Sending Data to OceanRemote Cloud

📤 Sending Data to OceanRemote - Complete Cloud Integration Guide

☁️ What You'll Learn in This Lesson:

Send sensor data from ESP32/ESP8266 to OceanRemote cloud
Master HTTP POST requests for IoT data transmission
Handle connection errors and implement retries
Optimize data payload size to save bandwidth
View your farm data from anywhere in the world

🌐 Why Send Data to the Cloud?

Without cloud connectivity, your sensor data stays on the device. With OceanRemote, you can:

Benefit	Description

📱 Remote Monitoring Check soil moisture from your phone anywhere 📊 Historical Data Track trends over days, weeks, or seasons ⚠️ Alerts & Notifications Get alerts when soil is too dry or temperature too high 📈 Data Analysis Make better farming decisions with historical data

📖 Complete OceanRemote Integration Code

/*
 * OceanRemote Cloud Integration - Complete Example
 * Send sensor data to OceanRemote from ESP32/ESP8266
 *
 * Features:
 * - HTTP POST with error handling
 * - Connection timeout
 * - Retry mechanism
 * - Data payload optimization
 *
 * Author: OceanRemote Education
 */

#include
#include

// ========== WIFI CONFIGURATION ==========
const char* ssid = "YOUR_WIFI_NAME";
const char* password = "YOUR_WIFI_PASSWORD";

// ========== OCEANREMOTE CONFIGURATION ==========
// Get your token from: OceanRemote Dashboard → Your Device → Generate Code
const char* token = "YOUR_DEVICE_TOKEN";
const char* serverUrl = "https://api.oceanremote.net/device/state";

// ========== SENSOR PINS (Example) ==========
#define SOIL_PIN 32
#define DHT_PIN 16

void setup() {
    Serial.begin(115200);
    delay(1000);

    Serial.println("========================================");
    Serial.println("🌍 OceanRemote Data Sender v1.0");
    Serial.println("========================================");

    // Connect to WiFi
    connectToWiFi();

    // Read sensors
    int soilMoisture = readSoilMoisture();
    float temperature = readTemperature();
    float humidity = readHumidity();

    // Send data to OceanRemote
    sendToOceanRemote(temperature, humidity, soilMoisture);

    // Optional: Deep sleep to save power
    // esp_sleep_enable_timer_wakeup(15 * 60 * 1000000);
    // esp_deep_sleep_start();
}

void connectToWiFi() {
    Serial.print("📡 Connecting to WiFi");
    WiFi.begin(ssid, password);

    int attempts = 0;
    while (WiFi.status() != WL_CONNECTED && attempts < 20) {
        delay(500);
        Serial.print(".");
        attempts++;
    }

    if (WiFi.status() == WL_CONNECTED) {
        Serial.println("\n✅ WiFi connected!");
        Serial.print("📶 IP: ");
        Serial.println(WiFi.localIP());
    } else {
        Serial.println("\n❌ WiFi connection failed!");
    }
}

int readSoilMoisture() {
    int raw = analogRead(SOIL_PIN);
    // Convert to percentage (calibrate for your sensor)
    int moisture = map(raw, 3800, 1500, 0, 100);
    moisture = constrain(moisture, 0, 100);
    return moisture;
}

float readTemperature() {
    // Replace with actual temperature sensor reading
    // Example: return dht.readTemperature();
    return 25.5;
}

float readHumidity() {
    // Replace with actual humidity sensor reading
    // Example: return dht.readHumidity();
    return 65.0;
}

void sendToOceanRemote(float temperature, float humidity, int soilMoisture) {
    if (WiFi.status() != WL_CONNECTED) {
        Serial.println("❌ Not connected to WiFi. Cannot send data.");
        return;
    }

    Serial.println("📤 Sending data to OceanRemote...");

    HTTPClient http;
    http.begin(serverUrl);
    http.addHeader("Content-Type", "application/x-www-form-urlencoded");

    // Build data payload
    String data = "token=" + String(token);
    data += "&temperature=" + String(temperature);
    data += "&humidity=" + String(humidity);
    data += "&soil_moisture=" + String(soilMoisture);

    // Optional: Add timestamp
    data += "×tamp=" + String(millis() / 1000);

    Serial.print("📦 Payload: ");
    Serial.println(data);

    // Send POST request
    int httpCode = http.POST(data);

    if (httpCode > 0) {
        Serial.printf("✅ Data sent! HTTP Code: %d\n", httpCode);

        if (httpCode == 200) {
            Serial.println("🎉 OceanRemote received your data!");
        } else if (httpCode == 401) {
            Serial.println("❌ Invalid token! Check your device token.");
        }
    } else {
        Serial.printf("❌ Failed to send data. Error: %d\n", httpCode);
        Serial.println("   Check WiFi connection and server URL.");
    }

    http.end();
}

void loop() {
    // Empty - everything happens in setup()
    // For continuous monitoring, move code here and add delay
}

🔐 Secure Data Transmission with Retry Logic

Production-ready code with error recovery:

/*
 * Secure Data Transmission with Retry Logic
 * Guarantees data delivery even with spotty WiFi
 */

#include
#include

const char* ssid = "YOUR_WIFI";
const char* password = "YOUR_PASSWORD";
const char* token = "YOUR_TOKEN";
const char* serverUrl = "https://api.oceanremote.net/device/state";

const int MAX_RETRIES = 3;
const int RETRY_DELAY_MS = 2000;

bool sendWithRetry(String data) {
    for (int attempt = 1; attempt <= MAX_RETRIES; attempt++) {
        Serial.printf("📤 Attempt %d/%d\n", attempt, MAX_RETRIES);

        // Ensure WiFi is connected
        if (WiFi.status() != WL_CONNECTED) {
            Serial.println("📡 Reconnecting to WiFi...");
            WiFi.reconnect();
            delay(1000);
        }

        HTTPClient http;
        http.begin(serverUrl);
        http.addHeader("Content-Type", "application/x-www-form-urlencoded");
        http.setTimeout(5000);  // 5 second timeout

        int httpCode = http.POST(data);

        if (httpCode == 200) {
            Serial.println("✅ Data sent successfully!");
            http.end();
            return true;
        } else if (httpCode == 401) {
            Serial.println("❌ Invalid token! Check your device token.");
            http.end();
            return false;  // Don't retry - token issue won't resolve
        } else {
            Serial.printf("⚠️ Attempt %d failed. HTTP Code: %d\n", attempt, httpCode);
            http.end();

            if (attempt < MAX_RETRIES) {
                Serial.printf("   Retrying in %d seconds...\n", RETRY_DELAY_MS / 1000);
                delay(RETRY_DELAY_MS);
            }
        }
    }

    Serial.println("❌ All retry attempts failed. Data will be sent next cycle.");
    return false;
}

void setup() {
    Serial.begin(115200);

    // Connect to WiFi
    WiFi.begin(ssid, password);
    while (WiFi.status() != WL_CONNECTED) delay(500);

    // Prepare data
    String data = "token=" + String(token);
    data += "&temperature=25.5";
    data += "&humidity=65.2";
    data += "&soil_moisture=45";
    data += "&battery=3.8";

    // Send with retry
    sendWithRetry(data);
}

void loop() {}

📦 Optimizing Data Payload for Low Bandwidth

Reduce data size for slow connections (2G/3G in rural areas):

/*
 * Optimized Data Payload for Low Bandwidth
 * Perfect for 2G/3G networks in rural Africa
 */

void sendOptimizedData(float temp, float hum, int soil, float batt) {
    if (WiFi.status() != WL_CONNECTED) return;

    HTTPClient http;
    http.begin("https://api.oceanremote.net/device/state");
    http.addHeader("Content-Type", "application/x-www-form-urlencoded");

    // Option 1: Full parameter names (readable, larger)
    // String data = "token=" + String(token) + "&temperature=" + String(temp);
    // Size: ~60 bytes

    // Option 2: Short parameter names (optimized, smaller)
    // String data = "t=" + String(token) + "&tmp=" + String(temp);
    // Size: ~40 bytes

    // Option 3: Binary encoding (very efficient, complex)
    // Not recommended for beginners

    // Recommended: Use short but clear names
    String data = "t=" + String(token);
    data += "&tmp=" + String(temp);      // temperature -> tmp
    data += "&hum=" + String(hum);       // humidity -> hum
    data += "&soil=" + String(soil);     // soil_moisture -> soil
    data += "&bat=" + String(batt);      // battery -> bat

    Serial.print("📦 Optimized payload size: ");
    Serial.print(data.length());
    Serial.println(" bytes");

    http.POST(data);
    http.end();
}

📊 Supported Data Parameters

OceanRemote accepts these parameters in your POST request:

Parameter	Type	Description	Example
token	Required	Device authentication token	oc_perm_xxxxx
temperature	Optional	Temperature in Celsius	25.5
humidity	Optional	Humidity percentage	65.2
soil_moisture	Optional	Soil moisture percentage	45
relay1..relay5	Optional	Relay states (1/0)	1
led_state	Optional	LED status (1/0)	0

🔧 Complete Sensor Station Example

/*
 * Complete Solar-Powered Sensor Station with OceanRemote
 * Sends soil moisture, temperature, humidity, and battery voltage
 * Deep sleep between readings for months of battery life
 */

#include
#include
#include

// ========== PINS ==========
#define SOIL_PIN 32
#define DHT_PIN 16
#define BATTERY_PIN 34
#define DHTTYPE DHT22

// ========== WIFI ==========
const char* ssid = "YOUR_WIFI";
const char* password = "YOUR_PASSWORD";
const char* token = "YOUR_TOKEN";

// ========== CALIBRATION ==========
const int SOIL_DRY = 3800;
const int SOIL_WET = 1500;

DHT dht(DHT_PIN, DHTTYPE);

// RTC counter
RTC_DATA_ATTR int bootCount = 0;

void setup() {
    Serial.begin(115200);
    bootCount++;

    Serial.println("========================================");
    Serial.printf("🌱 Sensor Station - Cycle #%d\n", bootCount);
    Serial.println("========================================");

    // Read sensors
    int soilRaw = analogRead(SOIL_PIN);
    int soilPercent = map(soilRaw, SOIL_DRY, SOIL_WET, 0, 100);
    soilPercent = constrain(soilPercent, 0, 100);

    dht.begin();
    float temp = dht.readTemperature();
    float hum = dht.readHumidity();

    int batteryRaw = analogRead(BATTERY_PIN);
    float batteryVoltage = batteryRaw * (3.3 / 4095.0) * 2.0;  // Voltage divider 2x

    // Print readings
    Serial.printf("💧 Soil moisture: %d%%\n", soilPercent);
    Serial.printf("🌡️ Temperature: %.1f°C\n", temp);
    Serial.printf("💧 Humidity: %.1f%%\n", hum);
    Serial.printf("🔋 Battery: %.2fV\n", batteryVoltage);

    // Connect to WiFi
    Serial.print("📡 Connecting to WiFi");
    WiFi.begin(ssid, password);
    int attempts = 0;
    while (WiFi.status() != WL_CONNECTED && attempts < 20) {
        delay(500);
        Serial.print(".");
        attempts++;
    }

    if (WiFi.status() == WL_CONNECTED) {
        Serial.println("\n✅ WiFi connected!");

        // Send data
        HTTPClient http;
        http.begin("https://api.oceanremote.net/device/state");
        http.addHeader("Content-Type", "application/x-www-form-urlencoded");

        String data = "token=" + String(token);
        data += "&soil_moisture=" + String(soilPercent);
        data += "&temperature=" + String(temp);
        data += "&humidity=" + String(hum);
        data += "&battery=" + String(batteryVoltage);
        data += "&boot_count=" + String(bootCount);

        int httpCode = http.POST(data);

        if (httpCode == 200) {
            Serial.println("✅ Data sent to OceanRemote!");
        } else {
            Serial.printf("❌ Failed! HTTP Code: %d\n", httpCode);
        }

        http.end();
        WiFi.disconnect(true);
        WiFi.mode(WIFI_OFF);
    } else {
        Serial.println("\n❌ WiFi failed - data will be sent next cycle");
    }

    // Deep sleep for 15 minutes
    Serial.println("💤 Going to deep sleep for 15 minutes...");
    esp_sleep_enable_timer_wakeup(15 * 60 * 1000000ULL);
    esp_deep_sleep_start();
}

void loop() {}

📖 Real-World Application - Zambian Maize Farm:

A farmer installed 5 soil moisture sensors connected to OceanRemote:

📡 Setup: ESP32 + capacitive soil sensor + solar panel
💧 Result: 45% water savings using moisture-based irrigation
📈 Yield: 32% increase in maize production
📱 Monitoring: Farmer checks soil moisture from phone while in town

"I never imagined I could monitor my fields from my phone. The data helps me water only when needed!" - Farmer, Zambia

⚠️ Common Issues & Solutions:

❌ HTTP 401 Unauthorized: Invalid token. Get a new token from OceanRemote dashboard.
❌ HTTP 404 Not Found: Wrong server URL. Use: https://api.oceanremote.net/device/state
❌ Connection timeout: WiFi signal weak. Move ESP32 closer to router.
❌ Data not appearing in dashboard: Check that parameter names match exactly (case-sensitive).
❌ ESP32 resets during POST: Power supply issue - add 1000μF capacitor.

📊 Testing Your Connection

Use this diagnostic sketch to verify your OceanRemote setup:

/*
 * OceanRemote Connection Tester
 * Verifies WiFi and API connectivity
 */

#include
#include

const char* ssid = "YOUR_WIFI";
const char* password = "YOUR_PASSWORD";
const char* token = "YOUR_TOKEN";

void setup() {
    Serial.begin(115200);
    delay(1000);

    Serial.println("🔧 OceanRemote Connection Tester");
    Serial.println("=================================");

    // Test 1: WiFi
    Serial.print("📡 Testing WiFi... ");
    WiFi.begin(ssid, password);
    int attempts = 0;
    while (WiFi.status() != WL_CONNECTED && attempts < 20) {
        delay(500);
        attempts++;
    }

    if (WiFi.status() == WL_CONNECTED) {
        Serial.println("✅ PASS");
        Serial.printf("   IP: %s\n", WiFi.localIP().toString().c_str());
        Serial.printf("   Signal: %d dBm\n", WiFi.RSSI());
    } else {
        Serial.println("❌ FAIL - Check SSID/password");
        return;
    }

    // Test 2: API Endpoint
    Serial.print("🌐 Testing OceanRemote API... ");
    HTTPClient http;
    http.begin("https://api.oceanremote.net/device/state");
    http.addHeader("Content-Type", "application/x-www-form-urlencoded");

    String testData = "token=" + String(token);
    testData += "&temperature=25.5";
    testData += "&test=1";

    int httpCode = http.POST(testData);

    if (httpCode == 200) {
        Serial.println("✅ PASS");
        Serial.println("   Data received by OceanRemote!");
    } else {
        Serial.printf("❌ FAIL - HTTP %d\n", httpCode);
        if (httpCode == 401) {
            Serial.println("   Invalid token! Check your device token.");
        }
    }

    http.end();
    Serial.println("\n✅ Test complete!");
}

void loop() {}

🎉 Congratulations!

You can now send sensor data to OceanRemote cloud!

✅ HTTP POST requests working

✅ Error handling and retries implemented

✅ Data payload optimization

✅ Complete sensor station example

🌍 Your farm data is now accessible from anywhere!

📚 Quick Reference - OceanRemote API:

// Endpoint
POST https://api.oceanremote.net/device/state

// Headers
Content-Type: application/x-www-form-urlencoded

// Required Parameter
token=YOUR_DEVICE_TOKEN

// Optional Parameters
temperature=25.5
humidity=65.2
soil_moisture=45
relay1=1
relay2=0
led_state=1

💡 Key Takeaways:

Apply these concepts directly to your farm or project.
Take notes on important details for the quiz.
Use the button below to track your progress.

← Previous Lesson Next Lesson →
