☀️ Solar Panel Selection and Sizing for IoT

☀️ What You'll Learn:

🔋 Calculate exactly how much solar power your sensor needs
📊 Choose between monocrystalline, polycrystalline, and thin film
⚡ Size batteries and panels correctly for year-round operation

Choosing the right solar panel is critical for off-grid sensors. An undersized panel means dead batteries. An oversized panel wastes money.

📊 Solar Panel Types

Type	Efficiency	Cost/Watt	Best For
Monocrystalline	18-22%	$0.80-1.20	Cloudy conditions, small space
Polycrystalline	15-17%	$0.60-0.90	Budget, sunny areas
Thin Film	10-12%	$0.50-0.70	Flexible, low light

🌟 Recommendation:

Monocrystalline panels are best for IoT because they work better in cloudy conditions and need less space.

📐 Solar Panel Sizing Formula

Example: 5-minute wake interval with soil moisture sensor

1. Daily power use:
   Active: 100mA × 5 seconds = 0.14mAh
   Sleep: 2.5μA × 3595 seconds = 0.0025mAh
   Total per cycle = 0.25mAh
   Cycles per day = 288
   Daily consumption = 72mAh

2. With 70% efficiency: 72mAh ÷ 0.7 = 103mAh/day

3. Panel wattage:
   5 sun hours/day: 103mAh ÷ 5 = 21mA
   6V × 21mA = 0.13W minimum
   ✅ Recommend: 6V 0.5W panel (4x margin)

Wake Interval	Daily Use	Panel Size	Battery
1 minute	360mAh	6V 2W	2000mAh
5 minutes	72mAh	6V 0.5W	1000mAh
15 minutes	24mAh	6V 0.2W	500mAh
1 hour	6mAh	6V 0.1W	200mAh

💡 Africa-Specific Tips:

Average sun hours: 5-6 hours/day in most of Africa
Rainy season: Oversize panel by 2x for cloudy weeks
Panel angle = latitude for optimal year-round production
Clean panels monthly - dust reduces output by 20-30%

⚠️ Common Mistakes:

❌ Using 5V panels → Battery needs 6V minimum
❌ No rainy season margin → Sensor dies in cloudy weather
❌ Wrong angle → Flat panels lose 40% of energy

🎉 Key Takeaways:

✅ Monocrystalline works best for African IoT
✅ Oversize panel 2-3x for rainy season
✅ 6V panels required (5V is not enough)
✅ Clean panels monthly, tilt at latitude angle
